How IPv4 Works – A Handbook for Developers

The Internet Protocol version 4 (IPv4) is one of the core protocols of standards-based internetworking methods in the Internet and other packet-switched networks. IPv4 is still the most widely deployed Internet protocol. Google’s IPv6 Statistics show 44.29% of traffic to Google services on April 24, 2025 is over IPv6, implying 55.71% goes over IPv4.

This handbook will take you through every aspect of IPv4, from understanding IP addresses to examining packet headers and fragmentation. You’ll learn:

• How IP addresses work and their different formats

• Network addressing schemes from fixed-length to CIDR

• Special IPv4 addresses and their uses

• The structure and purpose of every field in the IPv4 header

• How IPv4 handles packet fragmentation across different networks

Whether you’re a network engineer, software developer, or IT professional, understanding IPv4 is crucial for working with modern computer networks.

What we’ll cover:

1. Background

2. Understanding IP Addresses

3. Network ID and Host ID

4. How to Determine Network vs. Host Portions

5. Classful Addressing

6. CIDR: Classless Interdomain Routing

7. Subnet Masks

8. Interim Summary – IPv4 Addresses

9. Test Yourself

10. Special IPv4 Addresses

11. IPv4 Header

12. IPv4 Fragmentation

13. Summary – IPv4

14. About the Author

15. Additional References

Quick notes before we start

1. You can find more content about computer networks on my YouTube channel: Computer Networks Playlist

2. I am working on a book about Computer Networks! Are you interested in reading the initial versions and providing feedback? Send me an email: gitting.things@gmail.com

Background

IP stands for “Internet Protocol”, so IPv4 is Internet Protocol version 4. It was described in RFC 791 by IETF, published in September 1981, and first deployed for production in 1982 on SATNET (the Atlantic Packet Satellite Network), which was an early satellite network that formed an initial segment of the Internet.

IPv4 is connectionless and operates in a best-effort delivery model. This means it doesn’t guarantee delivery, correct ordering of packets, or the validity of the data. It’s designed to be fast and flexible.

Understanding IP Addresses

IP addresses are hierarchical, logical addresses that power most internet connections today. Each consists of 4 bytes, or 32 bits. They’re usually written in dotted decimal notation, for example:

Test yourself – Does the following address represent a valid IP address?

No. Since the dots separate different bytes, each value must be between 0 and 255. Since the number 392 is bigger than 255, it cannot be represented in a single byte.

Network ID and Host ID

IP addresses have two parts: a network identifier (or network ID) that belongs to all hosts in the network and a host identifier (or host ID) that identifies the specific host in this network.

The network identifier will be the same for all hosts in the network, and is also called a “prefix”. For example, consider a network identifier of 201.22.3. Given that this is the network prefix, the following addresses:

201.22.3.15
201.22.3.91

Are part of the same network, as they share the same prefix. The first address belongs to host number 15 in this network, and the second belongs to host number 91.

This address has a different prefix, or a different network identifier, and thus belongs to a different network:

201.22.14.50

In the examples above, there’s a network identifier consisting of 3 bytes, or 24 bits, and a host identifier consisting of 1 byte, or 8 bits.

How to Determine Network vs. Host Portions

A question arises: how do you know which bits are part of the network ID, and which are part of the host ID? Several approaches have evolved over time to address this challenge.

Fixed-Length Approach

Let’s consider this solution: For every IP address, the first, most-significant byte would represent the network ID, and the remaining three, least-significant bytes would represent the host ID. This way it’s really easy to read IP addresses. For example for this address:

20.12.1.92

You know that it describes network 20, and the host 12.1.92 inside that network. Any IP address that doesn’t start with 20, such as 22.1.2.3, would reside in a different network, and any IP address that starts with 20, like 20.1.2.3, would be within the same network.

What are the disadvantages here? 🤔

With only one byte (8 bits) to represent the network ID, you only have 2^8, or 256, different networks. Of course, there are far more networks than that in the real world. Even in the early days of the internet, universities and large companies each needed their own network identifiers.

In general, using a fixed length for the network ID and a fixed length for the host ID is not flexible enough. If you decide that the two most-significant bytes will represent the network ID and the two least-significant bytes will represent the host ID, you can represent up to 2^16, or 65,536 networks, which is also not enough. Furthermore, some networks, such as those of large companies, might require more than 65,536 host IDs.

Classful Addressing

The solution lies in providing some flexibility. Consider another approach called “classful addressing”. In this approach, the number of bits dedicated for the network ID changes from one address to another, and you can tell the network ID by looking at the first, most-significant byte of the address.

• Any address starting with a number between 1 and 127 belongs to “Class A”, meaning that its network ID consists of 1 byte, leaving 3 bytes for the host ID.

• Any address starting with a number between 128 and 191 belongs to “Class B”, which means that its network ID is 2 bytes long, and its host ID is also 2 bytes long.

• Any address starting with a number between 192 and 223 belongs to “Class C”, so it has 3 bytes of a network ID, and 1 byte of host ID.

You can see the full representation of this approach in the table below:

For example, what class does this address belong to?

(1) 130.12.204.5

Since it starts with 130, which is between 128 and 191, it belongs to “Class B”. This means that its network ID is 130.12, and its host ID is 204.5. Let’s mark it as “address number 1”.

Do this address and the following address (2) belong to the same network?

(2) 130.90.2.40

No, since they have different network identifiers, they are not within the same network.

What class does the following address belong to?

(3) 200.1.1.9

It belongs to class C, as the value of its first byte, 200, is between 192 and 223. This means that its network identifier is 200.1.1, and any address starting with this prefix will reside within the same network. This specific address describes host 9 within this network.

To complete the picture, addresses starting with a value between 224 and 239 belong to “Class D” – that is, multicast addresses – addresses that belong to multiple devices. Addresses starting with a value between 240 and 255 were reserved for future use. Addresses starting with 0 are special addresses.

IP Address Assignment

In the early internet, IPv4 addresses were assigned to organizations by the Internet Assigned Numbers Authority (IANA). As the internet grew, this responsibility was distributed to five Regional Internet Registries (RIRs) that handle address allocation for different geographic regions. Large organizations would receive blocks of addresses based on their needs, with address classes determining the size of these blocks.

What are the disadvantages here? 🤔

While classful addressing allows for more flexibility compared to the fixed-length approach, even this approach isn’t flexible enough.

Consider this scenario: A small startup company with just two founders needs a network identifier. Which class would they need?

Getting a class A or class B would be excessive, so they might get a class C – allowing 256 addresses. This is more than currently needed, but allows some expansion. What happens if the startup grows to more than 256 employees (and devices)?

At this point, they would need to get a class B address, giving no less than 65,536 addresses, when all they need is a bit over 256 addresses. This means wasting more than 60,000 addresses.

This became a real problem in the early 1990s as the internet was growing faster. The need for more IP addresses became apparent, and there was an impending exhaustion of the IPv4 address space. Cases where 60,000 addresses were wasted could no longer be tolerated.

CIDR: Classless Interdomain Routing

One of the measures to handle this shortage of addresses was to abandon classful addressing in 1993 and switch to another approach called CIDR – Classless Interdomain Routing. This approach is still used today.

CIDR allows for flexibility when choosing the network ID and the host ID. It lets network administrators create subnets of precisely the right size, rather than being limited to Classes A, B, or C.

Let’s start with a simple example. In CIDR notation, we add a suffix indicating how many bits are used for the network portion:

(4) 200.8.3.1/16

This slash notation specifies how many bits describe the network ID. In example (4) above, the first 16 bits (or 2 bytes) are used for the network ID. So, in this case, 200.8 is the network identifier, and 3.1 is the host identifier. The fact that 200.8 is the network ID means that all addresses from 200.8.0.0 through 200.8.255.255 are in this network.

Consider these additional addresses:

(5) 200.2.13.5
(6) 200.8.21.6

Given this address prefix of 16 bits, or 2 bytes, which of these addresses belong to the same network as example (4) (200.8.3.1/16)?

The first address (5) (200.2.13.5) does not belong to this network, as its first 16 bits – 200.2, are different from the first 16 bits of the example address.

The second address (6) (200.8.21.6) does belong to the same network as that of the example address.

Real-world Example

In practice, an ISP might receive a large block like 104.16.0.0/12 from the RIR. This gives them control of all addresses from 104.16.0.0 to 104.31.255.255. The ISP can then allocate smaller subnets to customers, such as giving a small business a /24 subnet with 256 addresses, or a larger company a /20 subnet with 4,096 addresses.

Subnet Masks

Another way to express the network prefix is by using a subnet mask, like so:

255.255.0.0

When converted to binary, 255 in decimal equals eight 1s in binary – so all bits are on. So if you translate this mask into binary, you get:

11111111 11111111 00000000 00000000

In other words, 16 bits are on, which means a network prefix of 16 bits. Both conventions (CIDR notation and subnet masks) are used very frequently.

With CIDR, an address can reside in different networks given different network prefixes, or subnet masks. If you consider the same example address with a different prefix, say that of 8 bits – both additional addresses would belong to the same network, as they all share the first 8 bits – 200.

How would you present a network prefix of 8 bits as a subnet mask? You need the first 8 bits to be on, so that means 255 in decimal, and the remaining bits are off, resulting in this subnet mask:

255.0.0.0

What happens if you use a network prefix of 24 bits? First, how would you express that as a subnet mask? You need 24 bits to be on, so that is 3 times 8 bits to be on, resulting in:

255.255.255.0

Now, neither of the additional addresses reside within the same network as the example address, as they don’t share its network ID of 200.8.3.

Note that network prefixes do not have to represent full bytes. For example, you can use a network prefix of 12 bits, or 11 bits, or 22 bits. When the prefix length isn’t a multiple of 8, the subnet mask will have a value other than 0 or 255 in one of its positions.

This addresses the issue regarding the startup company. If a startup has 300 employees, they’d need to get a 23-bits network ID, leaving 9 bits for hosts within their networks. This means 2^9, or 512 addresses, which should be sufficient.

Interim Summary – IPv4 Addresses

In this section, you’ve learned about IPv4 addresses. IP addresses are hierarchical, logical addresses that consist of 4 bytes. IP addresses have two parts: a network identifier that belongs to all hosts in the network, and a host identifier which identifies the specific host in the network.

You’ve explored various options for determining the network identifier and the host identifier:

1. Fixed-length approach – too rigid and limited

2. Classful addressing approach – better but still wasteful

3. CIDR (Classless Interdomain Routing) – flexible and efficient

CIDR provides much more flexibility and helps overcome the significant problem of IPv4 address shortage. However, CIDR is only one part of addressing the shortage of IPv4 addresses, with other solutions including NAT (Network Address Translation) and eventually, IPv6.

The next section will explore special IPv4 addresses and then examine the header of IPv4 packets.

Test Yourself

Now practice the concepts you’ve learned and make sure you feel comfortable with them.

Take a moment to try answering the following questions before checking the answers.

Converting Between Prefix Notation and Subnet Masks

How would you represent a network prefix of 16 bits, written like this /16, as a subnet mask?

You need 16 bits that are on. When 8 bits are on you get 255 in decimal, so you’d use:

255.255.0.0

Given this network prefix, do these addresses belong to the same network?

Yes, they do, as they share the same most-significant 16 bits, or two bytes

Does this address belong to the same network as that of the previous addresses?

Yes, it does. Again, it shares the same two most-significant bytes.

What about this one? Does it belong to the same network as the previous addresses?

No, as the first two bytes are not 42.31 – this is a different network. So this address describes host 1.2, within the network 42.32.

Working Backwards with Subnet Masks

Let’s try the other way around. You have this subnet mask:

255.255.255.0

How would you express it using a network prefix?

You have three occurrences of 255, which means three times 8 bits that are on, so overall you have 24 bits that are on. So you can also write /24. This means 3 bytes.

Given this subnet mask, do addresses (1) and (3) above belong to the same network?

They do, as they both have the same most-significant three bytes – network 42.31.93.

What about addresses (1) and (2)?

Given this network prefix, they don’t belong to the same network. The first address belongs to network 42.31.93, and the second address belongs to network 42.31.1.

Non-Byte-Aligned Prefixes

Network prefixes do not have to align to 8 bits, or full bytes. Let’s say you have a network prefix of 14 bits. How would you convert that to a subnet mask?

Well, the first byte is clear: you have 8 bits on, so the first byte is 255. What about the next one?

In binary, you’d want to have six additional 1s, and then 2 0s – so in binary you’d write:

11111100

Converting to decimal, this binary number represents 252. So your subnet mask is:

255.252.0.0

Another way to make this conversion: You know that eight 1s in binary represent 255 in decimal. You also know that 11 in binary is 3, so you can simply subtract 3 from 255 and get 252.

Next, try the other way around. You have the following subnet mask:

255.255.224.0

How many bits represent the network prefix?

The first two bytes are clear: you have 16 bits. Converting the third byte to binary: 224 in decimal is 11100000 in binary. This means you have an additional three 1s, so you can write the subnet mask above as a prefix of /19 bits – 16 bits for the two 255 bytes, and 3 additional bits for the 224 byte.

Determining Network Membership

Let’s consider the following addresses:

Are they part of the same network? 🤔

It depends on the subnet mask.

If the network prefix is /8, then they are part of the same network, as they share the same network ID.

On the other hand, if the network prefix is /16, then they have different network IDs, and thus don’t belong to the same network. But what happens with prefixes in between? Will they reside in the same network for a prefix of /9? /14?

The way to approach this question is to convert the second byte of these addresses to binary. For the first address, this byte is 24, which in binary is:

00011000

For the second address, the second byte is 23, which in binary is:

00010111

You can see that the most significant 4 bits within the second byte are identical. If you add the first 8 bits of the address, you see that the most significant 12 bits of these addresses are the same.

So, if you have a network prefix of /11, do these addresses belong to the same network?

Yes, they do – their most significant 11 bits are identical.

What about /13?

No, with this network prefix, they don’t share the same network identifier, as their 13th bit is different.

This practice should help you feel comfortable with subnet masks and network prefixes. In the next section, you’ll learn about special IP addresses and then examine the header of IP packets.

Special IPv4 Addresses

Now that you’re comfortable with IP addresses and subnet masks, let’s explore some IP addresses that have special meanings.

The “This Host” Address: 0.0.0.0

The address 0.0.0.0 means “this host” and is used in two scenarios:

First, when a machine boots up and doesn’t yet have an IP address. IP addresses are logical addresses that need to be assigned to a machine. Prior to this assignment, a device has no IP address at all. If the device needs to communicate at this stage, it may use this special address, 0.0.0.0.

Second, when writing network applications that need to listen for incoming connections on all network interfaces. For example, if a machine has two interfaces – one with the IP address 1.1.1.1, and another with the address 2.2.2.2 – listening on the address 0.0.0.0 means accepting connections regardless of which network interface receives them.

“This Network” Addresses

Another class of special addresses are those starting with zeros, where the zeros mean “this network.”

For example, if you have a machine with the address:

12.34.55.55

And a network prefix of 16 bits, this machine can send a packet to another device on the network using its full address, for example 12.34.66.66, or alternatively use the special zeros notation and send the packet to:

0.0.66.66

This means “send a packet to the host 66.66 on this network.” Of course, the recipient must also know the relevant network prefix to correctly interpret this address.

Broadcast Addresses

The address 255.255.255.255, where all bits are set to 1, is the address of all hosts in the local network – the broadcast address. This is similar to the broadcast address in Ethernet (FF:FF:FF:FF:FF:FF). In both cases, all bits are set to 1.

Using a proper network identifier where the host identifier is all set to 1s can be used to send a broadcast packet to remote networks. For example, consider a network 12.34.0.0/16 and another network with the network ID of 12.35.0.0/16. If a machine at 12.34.55.55 wants to send a packet to all devices in the other network, it could use the destination address: 12.35.255.255.

Even though this is allowed according to the IP specification (RFC), in practice this feature is often disabled as it can create security vulnerabilities.

Loopback Addresses: 127.0.0.0/8

All addresses in the network 127.0.0.0/8 (that is, all addresses that start with 127) are loopback addresses. Packets sent to any of these addresses are not put onto the physical network but are processed locally within the operating system. This is extremely useful for development and debugging.

For example, when developing a simple chat program, you need two clients that exchange data. One approach would be to use two different physical computers, but this is tedious – you’d need to write a message on one computer, check the other computer to see if it was received, then write a message on the second computer, and go back to the first to validate receipt.

A much simpler approach is to use a loopback address. Both clients can run on the same machine and connect with one another. You can run two different client programs on the same physical computer and exchange messages between them without needing an additional machine.

For instance, you might use the address 127.0.0.1, with one client listening on port 1337 and the other on port 1338. When client A sends a packet to client B, this packet never leaves your network card but remains within the operating system. Client B receives the packet from the loopback interface as if it had been received from the physical network.

After debugging is complete, your client code doesn’t need to change – the only difference is that they will communicate using real IP addresses instead of the loopback address.

Summary of Special IPv4 Addresses

To summarize the special IPv4 addresses you’ve learned about:

In the next section, you’ll learn about the structure of the IPv4 header.

Now that you understand IP addresses, subnets, and special addresses, it’s time to examine the IPv4 header structure in detail.

The diagram above shows the header of IPv4 as defined in RFC 791. Let’s examine each field:

Version (4 bits)

The header starts with the Version field, which consists of four bits. For an IPv4 packet, the version is 4, so this field will always carry the value of 4 (or 0100 in binary).

❓ Why does the header start with the Version field? 🤔

(Note – when I start a sentence with the ❓mark – it’s a question addressed at you, and I encourage you to try and answer it before reading on).

The reason is that the remaining fields may differ according to the version. If a network device reads an IP packet and the version field carries the value of 4, it will expect the remainder of the packet to follow the IPv4 structure. If it carries another value, such as 6, the remaining fields are different, as in IPv6.

This field indicates the length of the header itself.

❓ Why do we need to specify the length? 🤔

Unlike Ethernet, where the header size is fixed, the IPv4 header length can vary because of optional fields. For an IP packet without special options, the header consists of 20 bytes, which is the most common case.

The IHL field doesn’t specify the length in bytes directly but in units of 4-byte words. So to specify a length of 20 bytes, the value would be 5 (5 × 4 = 20). This encoding allows the field to use only 4 bits while specifying header lengths up to 60 bytes (when IHL = 15).

A common IPv4 packet therefore begins with the byte 0x45 in hexadecimal, meaning it’s version 4 of the IP protocol, and the header is 20 bytes long.

Type of Service (TOS) (8 bits)

The idea behind this field is that not all packets are equally important. You may want to give priority to some packets over others.

For example, packets carrying real-time data (like voice or video conferencing) are more time-sensitive than packets carrying, say, email or file downloads. If a router is currently experiencing high load, it should ideally prioritize time-sensitive packets.

The Type of Service field allows senders to indicate the priority of their packets. However, on the public internet, this field is often ignored by routers because any sender can set any priority value. In most cases, this field carries the value of 0.

Total Length (16 bits)

This field specifies the total length of the IP packet, including both the header and the payload (data).

❓ Why is this needed to specify the length? 🤔

Unfortunately, the IP layer doesn’t necessarily know if some of the bytes in the packet are actually a padding of the second layer. I described this in detail in a previous post, where I showed that in Ethernet protocol, in some cases, the receiving Ethernet entity cannot tell which bytes belong to the payload and which bytes are simply padding. The IP layer needs to know precisely which bytes belong to the actual packet, hence the Total Length field.

❓What is the maximum size of an IPv4 packet? 🤔

Since this field is 16 bits long, an IPv4 packet may contain a maximum of 2^16-1 bytes, or 65,535 bytes, including the header. The minimum size is 20 bytes, consisting of just the header without options or payload.

Fragmentation Fields (32 bits)

The next four bytes are dedicated to fragmentation control. I’ll cover these fields in a separate section, as they involve a complex topic deserving special attention.

Time to Live (8 bits)

Despite its name, this field doesn’t actually measure time but rather the maximum number of routing hops a packet can traverse before being discarded.

To understand its purpose, consider this scenario: If Machine A sends a packet to Machine B through a series of routers, but there’s a routing loop where Router 2 sends to Router 3, which sends to Router 4, which sends back to Router 2, the packet could circulate indefinitely, consuming bandwidth and never reaching its destination.

The TTL field prevents this by setting a limit on how many hops a packet can take:

1. The sender sets an initial TTL value (often 64 or 128)

2. Each router that handles the packet decrements the TTL by 1

3. If a router receives a packet with TTL = 1, it decrements it to 0 and discards the packet

4. The router then sends an ICMP “Time Exceeded” message back to the original sender

This doesn’t solve the underlying problem of routing loops, but it prevents packets from circulating forever.

In IPv6, this field is renamed “Hop Limit,” which more accurately describes its function.

Protocol (8 bits)

This field describes the payload of the IPv4 packet. For example:

This helps the receiving system know which protocol handler should process the packet’s contents. It’s similar to the Type field in Ethernet, which specifies the protocol of the layer encapsulated within the Ethernet frame.

This is a 16-bit checksum used to verify the validity of the header only (that is, excluding the payload). The sender computes this value based on the fields of the header, and the receiver also computes it to validate that the header was received correctly.

❓The checksum must be recalculated by each router. Why is that? 🤔

Because the TTL field changes at each hop. For example, if a packet starts with TTL = 7, each router will:

1. Verify the current checksum based on TTL = 7

2. Decrement TTL to 6

3. Calculate a new checksum based on TTL = 6

4. Forward the packet with the new checksum

If the checksum verification fails, the device drops the packet. This prevents packets with corrupted headers (which might have incorrect destination addresses, for instance) from being forwarded.

Source and Destination Addresses (32 bits each)

These fields contain the source and destination IPv4 addresses, respectively. Each is 4 bytes (32 bits) long, as you learned in the previous sections on IPv4 addressing.

Options (Variable Length)

Most IPv4 packets don’t include options, but when present, they can provide additional functionality:

• Record Route: Each router that handles the packet adds its own address to this option, creating a trace of the packet’s path

• Source Routing: Allows the sender to specify the route the packet should take:

  • Strict Source Routing: The entire route must be followed exactly

  • Loose Source Routing: Certain routers must be traversed, but the exact path between them is flexible

Padding

In some cases, the header ends with padding bytes (usually 0s).

❓Why does the IPv4 header have padding?🤔

As explained before, the IHL field specifies the header length in 4-byte units, so the total header length must be a multiple of 4 bytes. If options make the header length not divisible by 4, padding bytes (usually 0) are added to reach the next multiple of 4.

For example, if you have 3 bytes of options, you would need 1 byte of padding to make the total header length a multiple of 4 bytes.

You’ve now learned about the structure of the IPv4 header, with the exception of the fragmentation fields which I’ll cover in the next section.

The IPv4 header efficiently packs all the necessary routing and control information into a compact structure, typically 20 bytes long (without options). This design allows for fast processing by routers while providing the flexibility needed for internet communication. It is amazing how prominent IPv4 is, even so many years after its publication.

In the next section, you’ll learn about IPv4 fragmentation.

IPv4 Fragmentation

In the previous section, you learned about most of the IPv4 header structure, with the exception of 32 bits dedicated to fragmentation. This topic deserves special attention, as it reveals important aspects of how IP packets travel across different networks.

Why Fragmentation Is Needed

To understand what fragmentation is and why it’s needed, consider the following network scenario:

In this diagram, you have two different networks where Machine A resides in one network and Machine B resides in another. A router forwards packets between these two networks.

These two networks have different Maximum Transmission Units (MTUs). MTU refers to the maximum size of a frame that can be transmitted in a network. For example:

Different MTUs stem from the different protocols and hardware that different networks have. Ethernet has an MTU of 1500 bytes. This maximum size was chosen because RAM was expensive back in the late 1970s when Ethernet was planned, and a receiver would need more RAM if a frame could be bigger. Other networks were devised at different times where RAM prices might have been lower, or just have other considerations that affect the MTU.

Now, consider this scenario: Machine A wants to send a packet to Machine B. This packet is 1800 bytes long. From A’s perspective, there’s no problem since its network supports packets of this size. Machine A transmits the packet.

When the router receives this packet, it faces a problem: it cannot simply forward the packet to B’s network because the packet is too big for the network’s MTU. The router must fragment the packet – splitting it into smaller chunks of up to 1500 bytes, which will then be reassembled by Machine B.

How Fragmentation Works in IP

Let’s examine the scenario further. The router needs to take an IP packet of 1800 bytes and split it into two fragments, each consisting of up to 1500 bytes. If Machine A sends another packet of 1800 bytes to Machine B, the router will have to split that one too – resulting in four different fragments that will be reassembled into two separate packets.

When Machine B receives these fragments, it must ensure that it reassembles fragment #1 together with fragment #2 of packet A, and fragment #1 with fragment #2 of packet B – and not, for instance, fragment #1 of packet A with fragment #2 of packet B. It must also reassemble the fragments in the correct order – so structure a packet that consists of #1#2 and not #2#1.

Identification Field

First, focus on making sure Machine B reassembles fragments of the same packet (for example, fragment #1 and fragment #2 of packet A in the example above, rather than fragment #1 of packet A and fragment #2 of packet B). This is achieved using the identification field of IPv4. Fragments belonging to the same packet will have the same identification value. For example, both fragments of packet A might have identification set to 100, and both fragments of packet B might have identification of 200.

It’s important to note that sharing identification values isn’t sufficient for fragments to belong to the same packet. Fragments of the same packet must also share:

• The same source IP address

• The same destination IP address

• The same protocol value (indicating whether the payload is TCP, UDP, and so on)

Fragment Offset

Since IP is a connectionless protocol, there’s no guarantee that fragments will arrive at Machine B in the correct order. Fragment #2 of packet A may arrive before fragment #1. To handle this issue, each fragment carries an Offset field, which denotes the offset from the beginning of the original packet.

The Offset field consists of 13 bits, which means it can carry values from 0 to 8191 (2^13-1). This poses a potential problem, as the maximum size of an IP packet can be 65,535 bytes (since the Total Length field of the IP header consists of 16 bits).

To address this limitation, the value encoded in the Offset field is actually multiplied by 8 (2^3). This means the minimum size of a fragment is 8 bytes, with the exception of the last fragment.

❓Why do IP packets carry an offset in bytes divided by 8, instead of just a sequential fragment number?🤔

While using sequence numbers might seem simpler, it would create problems when packets need to be fragmented multiple times.

For example, if Computer A sends a packet to the first router, which fragments it into pieces of 1480 bytes and 320 bytes, and then these fragments are sent to another router that needs to fragment them again into even smaller pieces, how would you number them?

With byte offsets, the solution is straightforward – if the first fragment has an offset of 0 and the next one has an offset of 1480, then if we need to split them into maximum 800-byte fragments, we’d have:

• First fragment: 800 bytes with offset 0

• Second fragment: 680 bytes with offset 800

• Third fragment: 320 bytes with offset 1480

More Fragments and Don’t Fragment Flags

When Machine B receives a fragment, it needs to know whether this is an entire packet by itself or if it should expect additional fragments. For this purpose, each IP fragment carries a More Fragments (MF) bit that is set to 1 for every fragment that is not the last fragment of the packet. For the last fragment, it’s set to 0.

In case the packet consists of a single fragment – the MF bit will be set to 0, and the offset field will also hold the value 0 (that is, 13 bits of 0s).

Another bit related to fragmentation is the Don’t Fragment (DF) bit. When this flag is turned on, intermediate devices should not fragment the original packet, even if it exceeds the MTU. Instead, they should drop it and typically send an ICMP “Fragmentation Needed” message back to the source.

In our example, if Machine A sets the Don’t Fragment bit to 1, the router would drop the packet, and notify Machine A about it.

Note that right after the identification field and before the DF flag, there is a reserved bit set to 0. This bit was reserved in case it is needed in the future, for a reason unknown to the original authors of IPv4.

Fragmentation Example

Consider again our example above – with Machine A residing in a network where the MTU is 2000, and Machine B residing in a network where the MTU is 1500. Machine A sends a packet which is 1800 bytes long.

❓Can you fill the values in these tables?

First Fragment:

Second Fragment:

For our example above, the values of the relevant fragmentation fields in IP would be as follows:

First Fragment:

• Total Length: 1500 (including 20 bytes of IP header, so 1480 bytes of payload)

• Identification: 1337 (arbitrary value)

• Don’t Fragment bit: 0 (off, to allow further fragmentation if needed)

• More Fragments bit: 1 (on, as this is not the last fragment)

• Offset: 0 (it’s the first fragment)

Second Fragment:

• Total Length: 340 (including 20 bytes of IP header, so 320 bytes of payload – together with the first fragment, we get to 1800 bytes of payload)

• Identification: 1337 (same as first fragment, indicating they belong together)

• Don’t Fragment bit: 0 (off, to allow further fragmentation if needed)

• More Fragments bit: 0 (off, as this is the last fragment)

• Offset: 185 (1480/8 = 185, or 0xB9 in hexadecimal)

IPv4 Fragmentation – Summary

You’ve now learned about the final part of the IPv4 Header: fragmentation. Fragmentation is necessary to allow packets to travel across networks with different MTUs. The IPv4 header includes several fields specifically designed to support fragmentation:

• Identification (16 bits): Identifies which fragments belong together

• Flags (3 bits): Including the “More Fragments” and “Don’t Fragment” flags

• Fragment Offset (13 bits): Indicates where in the original packet this fragment belongs

With this knowledge, you now understand every bit and byte of the IPv4 header and how IP packets can traverse networks with different characteristics.

Summary – IPv4

In this comprehensive guide to IPv4, you’ve learned about the fundamental building blocks of Internet communications. Let’s recap the key concepts we covered:

Addressing and Network Structure

• IPv4 addresses are 32-bit numbers typically written in dotted decimal notation

• Networks can be identified using various methods:

  • Fixed-length approach (historically)

  • Classful addressing (A, B, C, D, E classes)

  • CIDR (modern approach allowing flexible network sizes)

• Special addresses serve specific purposes:

Fragmentation

Final Words

While IPv4 has limitations, particularly its address space constraints, its elegant design and robust features have allowed it to remain the backbone of the Internet for over four decades. Understanding IPv4 provides essential context for working with modern networks and helps in transitioning to newer protocols like IPv6.

About the Author

Omer Rosenbaum is Swimm’s Chief Technology Officer. He’s the author of the Brief YouTube Channel. He’s also a cyber training expert and founder of Checkpoint Security Academy. He’s the author of Gitting Things Done (in English) and Computer Networks (in Hebrew). You can find him on Twitter.

Additional References
